IP Subnet Calculation & Design

IPX network numbers for Royal Palm:  Student net-32 - Admin net- 16

-----------------------------------------------------------------------------
IP Class:       A              IP Address:      10.0.0.0
Mask Bits:      11             Subnet Mask:     255.255.224.0
Subnets:        2046+1         IP Major Net:    10.0.0.0
Hosts/Subnet:   8190           Major Net Bcast: 10.255.255.255



                  Subnets for Fixed Length Subnet Masking
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
  No.     Subnet           Hosts            Hosts            Broadcast
          Address          From             To               Address



       0  10.0.0.0         10.0.0.1         10.0.31.254      10.0.31.255
       1  10.0.32.0        10.0.32.1        10.0.63.254      10.0.63.255
       2  10.0.64.0        10.0.64.1        10.0.95.254      10.0.95.255
       3  10.0.96.0        10.0.96.1        10.0.127.254     10.0.127.255
       4  10.0.128.0       10.0.128.1       10.0.159.254     10.0.159.255
       5  10.0.160.0       10.0.160.1       10.0.191.254     10.0.191.255
       6  10.0.192.0       10.0.192.1       10.0.223.254     10.0.223.255
       7  10.0.224.0       10.0.224.1       10.0.255.254     10.0.255.255
       8  10.1.0.0         10.1.0.1         10.1.31.254      10.1.31.255
       9  10.1.32.0        10.1.32.1        10.1.63.254      10.1.63.255
      10  10.1.64.0        10.1.64.1        10.1.95.254      10.1.95.255
      11  10.1.96.0        10.1.96.1        10.1.127.254     10.1.127.255
      12  10.1.128.0       10.1.128.1       10.1.159.254     10.1.159.255



    2032  10.254.0.0       10.254.0.1       10.254.31.254    10.254.31.255
    2033  10.254.32.0      10.254.32.1      10.254.63.254    10.254.63.255
    2034  10.254.64.0      10.254.64.1      10.254.95.254    10.254.95.255
    2035  10.254.96.0      10.254.96.1      10.254.127.254   10.254.127.255
    2036  10.254.128.0     10.254.128.1     10.254.159.254   10.254.159.255
    2037  10.254.160.0     10.254.160.1     10.254.191.254   10.254.191.255
    2038  10.254.192.0     10.254.192.1     10.254.223.254   10.254.223.255
    2039  10.254.224.0     10.254.224.1     10.254.255.254   10.254.255.255
    2040  10.255.0.0       10.255.0.1       10.255.31.254    10.255.31.255
    2041  10.255.32.0      10.255.32.1      10.255.63.254    10.255.63.255
    2042  10.255.64.0      10.255.64.1      10.255.95.254    10.255.95.255
    2043  10.255.96.0      10.255.96.1      10.255.127.254   10.255.127.255
    2044  10.255.128.0     10.255.128.1     10.255.159.254   10.255.159.255
    2045  10.255.160.0     10.255.160.1     10.255.191.254   10.255.191.255
    2046  10.255.192.0     10.255.192.1     10.255.223.254   10.255.223.255
    2047  10.255.224.0     10.255.224.1     10.255.255.254   10.255.255.255
